MW-2 Oil mist purifier
MW-2 Oil mist purifierApplied range
Suitable for the collection, recycling and air purification of oil mist from coolant (emulsion or cooling oil) used in cutting or machining.
Product description
1. The MW 2 mini oil mist purifier is compact in design, small in size and light in weight.
2. The purifier can be installed directly on the upper part of the equipment without taking up space
3. A small fan can be used to connect directly to the purifier, or a central fan can be used to connect separately to the purifier through pipes.
Specification
| Product model | MW-2 |
| Airflow | 550 m3/h |
| Net weight | 13 kg |
| Air inlet dimension | 159 mm |
| Air outlet dimension | 159 mm |
| Material enclosure | Galvanized steel sheet |
| Box surface treatment | Epoxy powder coating |
| Filter pressure indicator | 0-1000 pa |
| Filter area of filter element | 10 m2 |
| Filter efficiency | 95 % |
